AiM MXS Strada 1.2 with icons 5" Dash

  • Sale
  • Regular price $ 2,123.00 AUD
Tax included. Shipping calculated at checkout.


A wide range of data sources

MXS 1.2 Strada, the evolution of MXS Strada, is a 5" color display with great visual impact, configurable to show lap times and all the info coming from the Engine Control Unit, analog/digital inputs, pre-defined math channels and - optionally - the GPS08 Module.

CAN output

With the CAN Output you can send messages directly to an existing CAN network in order to improve the range of vehicle control possibilities.

High contrast TFT display

MXS Strada 1.2 features a high contrast TFT display: its visual quality is always optimal as its ambient light sensor keeps the backlight at the best brightness levels.

This version of the dash includes the "Street Icons" needed by street users (fuel, oil, water temp., etc.). MXS Strada is also available in a version without icons. Please refer to MXS Strada Standard separately.

Watch your data in pre-configured pages

MXS 1.2 Strada shows, together with RPM scale, all the data you need, like speed, water temperature and oil pressure, laptimes and much more... You can choose the custom pages from a wide library of page styles, defining which data to be shown, their end of scale and measure units. Swapping between pages is quite easy using the pushbuttons.

Flexible alarms

The ten multicolored RGB shift lights can be customized as you like, defining the RPM threshold for each single gear. The same flexibility applies to the configurable RGB alarm LEDs: you can configure them in order to turn them on/off depending on analog or digital inputs, ECU values, expansion values, math channels or - optionally - GPS information. You choose conditions and colors: select a solid alarm or flashing one - and the flashing frequency. It is also possible to configure an accompanying text message, and set the alarm priorities.

Two digital outputs

MXS 1.2 Strada features a LOW SIDE type (switch to ground) digital output configurable in order to be activated/deactivated depending on the value of the analog/digital inputs or on impulses coming from the ECU.This permits to automatically run external systems, i.e. to switch on/off additional lights, to activate/de-activate a cooling fan or circulation pumps, etc. when a certain event happens.

A modular system

Using the built-in CAN bus you can add expansion modules to visualize additional info:

- GPS08 Module

- Channel Expansion

- TC Hub

- LCU-One CAN

- SmartyCam HD cameras

Race Studio 3 configuration

MXS 1.2 Strada is to be configured via Race Studio 3: you can create, modify, delete, import and export configurations with all channels, ECU drivers, math channels, display pages, digital output, alarms, shift lights and all the expansions you need.
